RFS 158EIA-HCA78-020 — Радиочастотный соединитель HCA78-50 Series 7/8″ · 1-5/8″ EIA

Радиочастотный соединитель RFS Technologies / Amphenol · 158EIA-HCA78-020.

Ключевые характеристикиВсе характеристики

Интерфейс соединителя: 1-5/8" EIA

Вид соединителя: None

Тип соединителя: RAPID FIT™

Запросить цену

Сохранить товар:

О товаре

Описание

RFS 158EIA-HCA78-020 — Радиочастотный соединитель HCA78-50 Series 7/8″ · 1-5/8" EIA — Радиочастотный соединитель производства RFS Technologies / Amphenol.

¹) The sealing compound must be ordered separately.

Основные характеристики

Интерфейс соединителя: 1-5/8" EIA
Вид соединителя: None
Тип соединителя: RAPID FIT™

Описание производителя

Оригинальный текст (EN). Перевод не выполнен.

Related Products High performance coaxial cable connectors are designed specifically to provide the highest quality connector-cable interface while simplifying and speeding up the attachment of connectors to air dielectric coaxial cables. Connectors are fully tested for mechanical and electrical compliance specifications. They are available in all popular cable sizes in a variety of mating interfaces. To join two cables with EIA connectors, two identical socket connectors are installed on either end of the cables to be joined, and a coupling element is used to make the connection of the center conductor. The coupling element must be ordered separately with the exception of the S-Line male versions that have a captivated coupling element. Connectors are available in sizes matching the nominal cable size. EIA connectors provide optimal power handling for the complete transmission line system.

Особенности и преимущества

Excellent gas tightness, Overpressure for increased voltage handling is maintained throughout the system
Robust Mechanical Design, Superior and consistent performance guarantees outstanding system characteristics.
Extremely low reflection factor, Outstanding low reflection factor improves overall system performance and margin and reduces mismatch losses
Totally Waterproof according to IP 68, Assures safe, long term operation in the harshest of environments. System tightness doesn't have to rely on overpressure from dehydration equipment.
