RFS HOIST1-158L — Гибридный кабель

Гибридный кабель RFS Technologies / Amphenol · HOIST1-158L.

Ключевые характеристикиВсе характеристики

Тип кабеля: Air Dielectric, Foam Dielectric

Запросить цену

Сохранить товар:

О товаре

Описание

RFS HOIST1-158L — Гибридный кабель — Гибридный кабель производства RFS Technologies / Amphenol.

Hoisting Grip Size and Max Cable Length Table.

Cable Size Range, in (mm)

Max Interval if Cable is Under 2 lb/ft, ft (m)

Max Interval if Cable is Over 2 lb/ft, ft (m)

0.6 — 0.74 (15.2 — 19.1)

0.75 — 0.99 (19.1 — 25.4)

Основные характеристики

Тип кабеля: Air Dielectric, Foam Dielectric

Описание производителя

Оригинальный текст (EN). Перевод не выполнен.

Related Products Hoisting and support grips provide an effective means to secure cable into position while lifting. The hoisting grip is manufactured from stainless steel wires and becomes a mesh and hold the cable by friction over their complete length when pulled. Two types of the hoisting grip are available for most cable types. The closed (pre-lnced) version is used when the top connector is installed after the cable is hoisted, while the open (lace-up) version is used in cases the top connector is installed prior to hoisting the cable.

Особенности и преимущества

Hoisting stockings distribute the force during installation
It holds the transmission line by means of friction over their complete length
The closed version (C-Type) is used when top connector is installed after the antenna transmission line is hoisted
The open version (L-Type) is used where the top connector is installed prior to the hoisting

Параметры

Технические характеристики

Комплектация и упаковка

Количество в упаковке: 1 шт.

Основное

Продуктовая линия: Coaxial Cable Accessories, Elliptical Waveguide Accessories, Hybrid Cable Accessories
Производитель: RFS Technologies / Amphenol
Бренд: RFS

Тип и назначение

Тип линии передачи: LCF158, HCA158, E60, EP60, E65, EP65, HB158
Тип кабеля: Air Dielectric, Foam Dielectric

Рабочие данные

Частотные характеристики

Технические данные производителя

12 строк

Model Number	Cable Size Range, in (mm)	Max Interval if Cable is Under 2 lb/ft, ft (m)	Max Interval if Cable is Over 2 lb/ft, ft (m)
HOIST1-12L	0.6 - 0.74 (15.2 - 19.1)	200 (65)	150 (49)
HOIST1-12C	0.6 - 0.74 (15.2 - 19.1)	200 (65)	150 (49)
HOIST1-58L	0.75 - 0.99 (19.1 - 25.4)	200 (65)	150 (49)
HOIST1-58C	0.75 - 0.99 (19.1 - 25.4)	200 (65)	150 (49)
HOIST1-78L	1 - 1.34 (25.4 - 34.3)	200 (65)	150 (49)
HOIST1-78C	1 - 1.34 (25.4 - 34.3)	200 (65)	150 (49)
HOIST1-114L	1.35 - 1.74 (34.3 - 44.5)	200 (65)	150 (49)
HOIST1-114C	1.35 - 1.74 (34.3 - 44.5)	200 (65)	150 (49)
HOIST1-158L	1.75 - 1.99 (44.5 - 50.5)	200 (65)	150 (49)
HOIST1-158C	1.75 - 1.99 (44.5 - 50.5)	200 (65)	150 (49)
HOIST1-214L	2 - 2.5 (50.8 - 63.5)	200 (65)	150 (49)
HOIST1-214C	2 - 2.5 (50.8 - 63.5)	200 (65)	150 (49)
