RFS NM-LCF114-C02 — Радиочастотный соединитель 1-1/4″ · N

Радиочастотный соединитель RFS Technologies / Amphenol · NM-LCF114-C02.

Ключевые характеристикиВсе характеристики

Интерфейс соединителя: N

Вид соединителя: Male

Тип соединителя: OMNI FIT™ Standard

Волновое сопротивление: 50 Ом

Максимальная рабочая частота: 3,6 ГГц

Запросить цену

Сохранить товар:

О товаре

Описание

RFS NM-LCF114-C02 — Радиочастотный соединитель 1-1/4″ · N — Радиочастотный соединитель производства RFS Technologies / Amphenol.

Основные характеристики

Интерфейс соединителя: N
Вид соединителя: Male
Тип соединителя: OMNI FIT™ Standard
Волновое сопротивление: 50 Ом
Максимальная рабочая частота: 3,6 ГГц

Описание производителя

Оригинальный текст (EN). Перевод не выполнен.

Related Products OMNI FIT™ high performance connectors are designed for use with both CELLFLEX® (copper) and CELLFLEX® Lite (aluminum) cables. They are designed specifically to provide the highest quality connector-cable interface while simplifying and speeding up connector attachment. All RFS Technologies connectors are fully tested for mechanical and electrical compliance to industry specifications. The N connector is one of the most common RF connector types and meets all requirements even under the most severe environmental conditions.

Особенности и преимущества

Cost effective two-piece design for safe and easy installation
Compatible with copper and aluminium cable types i.e. one connector for both outer conductor materials eliminates the risk of faulty connector installation and helps to keep inventory down
Robust mechanical design for low and consistent intermodulation performance i.e. keeps the mobile network performance up, reduces the number of dropped calls and avoids revenue losses
Standard electrical performance for consistent and repeatable VSWR i.e. ensure network system performance
Waterproof to IP 68 i.e. no downtime risk, secures revenue
RoHS (EU) compliant i.e. can be used on a global basis
OMNI FIT™ Standard Connectors
